I have used most of these parts in my own Fritzing diagrams, although Ive never tried to fabricate a PCB using Fritzing drawings (my interest is primarily in the documentation and illustration of hardware configurations). These are pin-out compatible (not software compatible) with the Senseair S8 CO2 sensorįor this purpose the air intake opening of the S8 sensor is also drawn in the silk screen to make it easier to add an opening in the PCB. Just click on the link to download the file, then double click on the file to open Fritzing and import the part. The MH-Z19 and the MH-Z19B are quite affordable CO2 sensors. The larger 1.3" OLED monochrome displays use the SSH1106 chip.

Available on Banggood Blue or White (affiliated links).

These display only every other line, so they remain compatible with the existing libraries for the 128圆4 displays. The 0.91" displays are quite small and only show 32 pixels height.

GND-VCC-SCL-SDA version available on Banggood (affiliate link).

There are two versions of these displays, with only the GND and VCC swapped. NodeMCU V1.0: this is the second incarnation of the ESP8266 based dev board. Where I used his Fritzing parts, I left his credentials in the Fritzing parts. Some of his Fritzing parts, I made improvements on, but I also added some myself.

You can download here, and import for your parts ESP32 DevKitc V4 ready parts submit ESP32 DevKitc V4.fzpz (137.7 KB) Me and my friend redesigned the pins for Breadboard and Pcb. This repository started as a fork from Daniel Eichhorn (Squix78), the author of many fine projects like the OLED display library. Peter matasoy October 26, 2022, 9:06am 3 We add an ESP32 Devkitc V4 as 38 pin. Where applicable, both the breadboard and the silkscreen are designed. This repository contains parts for the Fritzing application.
